Introduction:
RW/CW SPDP Low voltage slipring induction motors are designed for heavy duty use with a driven machine imposing overloads and severe mechanical shocks and vibrations. Because of optimum utilization of materials, with improved ventilation techniques the motors are 10 – 15% lighter in weight and yet more rugged because of their inherent special construction. Because of the high Pull-Out Torque and inherent thermal margin kept for high slip operation (with suitable external resistance), these motors are ideally suited for rerolling mills and cane cutter/cane crusher/cane leveler/cane fiberize applications pertaining to sugar industries.
Features:
- Design for Heavy duty application.
- Accommodate severe mechanical shocks & vibration.
- Improved ventilation technique.
- High Pullout Torque.
- Suitable for demanding applications.
- Inherent thermal margin leads to High Performance.
- Compliance with IEC Class IV duty.
- Easy access to brush gear sliprings.
Specifications:
- RW Frame Sizes: RW89 to RW 168
- CW Frame Sizes: IEC 450 TO IEC 710
- Power Rating: 90kW to 2000 kW
- Power Supply: AC 3 Phase , 415V+/- 10%, 50 Hz +/- 5%;
- Pole: 6 to 12
- Protection: IP21, IP23 (IS 4691)
- Insulation Class: Class F with temperature rise limited to class B
- Ambient Temperature: 45°C
Applications:
Rolling mills and cane cutter/cane crusher/cane leveler/cane fiberizer applications.
