Introduction:
These fans are backed by extensive knowledge of design and application engineering of last 50 years of India’s largest manufacture of fans and aided by latest manufacturing facility using CNC machine tools. The products included in this catalogue are available off the shelf from local dealers/ godowns located throughout the country. The plant is certified by BVQI for ISO9001quality management system. All fans are CE®* certified.
Major Applications:
These fans support applications such as Industrial Ventilation, Large Kitchen Ventilation, Transformer Cooling, Evaporative Air Cooler, Condenser Cooling, Controlled Air Movement.
Features:
- 300 mm to 915 mm diameter.
- Volume flow from 1200 m3 per hour to 28000 m3 per hour.
- Static pressure upto 150 pa (15mm WG).
- SN series fan 60 Hz are available.
- CE marked fan available for European market.
- Extruded/pressure die cast shell with provision for accurate positioning of impeller assembly to derive best air performance under static pressure.
- Unique fastening system with improved rigidity.
- Maintenance free operation.
