Introduction:
Fire Fighting Motors are specialized electric motors designed to drive fire pumps that deliver water or fire-extinguishing agents to suppress fires. They ensure reliable operation during emergencies and are an integral part of fire suppression systems in commercial, industrial, and residential settings.
Features:
- Durability: Built to withstand harsh environments and extreme conditions.
- Reliability: Consistent performance when it matters most.
- High Starting Torque: Efficiently powers fire pumps from start to operation.
- Corrosion Resistance: Constructed with materials that ensure long-lasting use.
- IP55 Protection: High ingress protection against dust and water.
Specifications:
- Output: 5.5kW to 75kW (7.5HP to 100HP)
- Pole: 2 pole
- Frame: IEC® 112-280
- Standards: IS 12615 / IEC 60034 certified
- Power Supply: Standard 415V, 50Hz (custom voltages & frequencies available)
- Ambient Temperature: Up to 50°C (higher on request)
- Construction: Cast iron with integrally cast feet
- Terminal Box: Sheet metal (up to 225) / Cast iron (250 and above)
- Connection: Star Less than or equal to 3kW, Delta (Greater than 3kW)
- Protection: IP55 (higher classes on request)
- Insulation: Class F
- Bearings: Ball bearing
- Fan: Bi-directional
- Mounting: Standard B3, B5, B35, V1 (plus B14, B34 for IEC 80-132)
- Paint: RAL 3573
Applications:
Commercial buildings, industrial facilities, residential complexes, marine and offshore installations, and public infrastructure.
Standard & Certification:
Fully compliant with IS 12615 and IEC 60034 standards, guaranteeing safety, quality, and international compliance.
