Introduction:
One of India’s most modern motor factories, incorporating extensive CAD facilities with over 50 years of experience in the design and application of induction motors, enables Marathon to offer the benefits of proven solutions.
Features:
- Marathon has over 2500 MW installed world-wide.
- Highest available efficiency - rapid payback.
- High power factor - low power cost.
- Resivac VPI insulation system for total winding reliability.
- Highest quality - lowest maintenance costs.
- Low Noise Level - better performance than IS:12065.
- Low vibration level - conforms to IS:12075.
- Compliance with National and International Standards.
- Variable speed drive compatibility.
- Slipring version available.
Specifications:
- Frame: IEC 315 to IEC 710
- Power Rating: upto 5 MW
- Voltage: 3.3KV / 6.6KV / 11KV
- Frequency: 50Hz +- 5%
- Pole: 2 to 14
- Air-cooled CACA IC 0161, Water-cooled CACW IC 8A1W7
Applications:
Air Compressor in power plant/ steel plant, Fan & blower motors, Conveyor motors, paper plant, crushers motors
